The accumulation distribution line (A/D line) is a running total of volume, where each bar’s volume is weighted by where the close sits inside the bar’s range. A close at the high adds the full volume, a close at the low subtracts it, and a close in the middle adds nothing. Marc Chaikin developed it, under the original name of Cumulative Money Flow Line. A rising line is read as accumulation, buying pressure, and a falling line as distribution. Below, the formula, the one weakness StockCharts points out, and a real day when the A/D line and on-balance volume moved in opposite directions.

Accumulation distribution line on the daily S&P 500 ETF

Accumulation/Distribution Line on S&P 500 ETF, dividend-adjusted prices, daily, October 30, 2025 to October 28, 2026. Illustration of how the indicator reads, not a backtest.
  • Price, daily candles (hollow up, filled down)
  • A/D line, cumulative money flow volume (solid line)
Accumulation/Distribution Line on S&P 500 ETF, dividend-adjusted prices, daily, October 30, 2025 to October 28, 2026. Illustration of how the indicator reads, not a backtest.

How the A/D line is calculated

The calculation has three steps. The money flow multiplier places the close in the bar’s range on a scale from −1, a close at the low, to +1, a close at the high. Multiplied by the bar’s volume it gives the money flow volume. The A/D line adds each bar’s money flow volume to the running total.

How the A/D multiplier reads the close

How the A/D multiplier reads the close: three bars with the same range: a close at the high gives a multiplier of +1, a close in the middle 0, a close at the low −1. A fourth bar gaps down below the previous close and closes near its own high: its multiplier is near +1 although the price fell from the day before.
Schematic, not market data.The multiplier only looks inside the bar: a gap down that closes near its own high still counts as buying.

The level of the line has no meaning on its own: it depends on the day the sum started. On the A/D chart at the top of the page, our total starts with the first bar of our series in June 2024, so only the direction and the slope of the line are worth reading.

How to read it

  • Confirmation: a rising A/D line in an uptrend says that closes are mostly near the highs on volume, which supports the move.
  • Divergence: a price that makes new highs while the A/D line falls is read as distribution under the surface, and the reverse as accumulation. See divergence.
  • Accumulation and distribution phases: the same words name the trading ranges of the Wyckoff method, which StockCharts describes as accumulation and distribution phases; the A/D line is one way to look for them in volume.

The weakness: gaps are invisible

StockCharts warns that “the Money Flow Multiplier does not take into account price changes from period to period.” The multiplier only looks at the bar itself, so a stock that gaps down and then closes near the top of its day range adds to the A/D line even though it lost value. StockCharts illustrates it with a big gap down on Clorox. This is where the A/D line differs most from on-balance volume, which adds or subtracts the whole volume according to the change from the previous close.

A real example on the daily S&P 500 ETF: on March 3, 2026 the ETF opened 1.65% below the previous close, fell further, then recovered to close near the top of its range, still 0.88% lower than the day before.

March 3, 2026Value
Previous close681.06
Open, high, low, close669.83, 677.32, 664.47, 675.06
Volume105.0 million shares
Money flow multiplier0.65
Change in the A/D line+68.0 million
Change in on-balance volume−105.0 million

Same day, same data, opposite readings: the A/D line counted a day of buying pressure, on-balance volume a day of selling.

On-balance volume on the same 250 days of the S&P 500 ETF

OBV, signal SMA(20) on S&P 500 ETF, dividend-adjusted prices, daily, October 30, 2025 to October 28, 2026. Illustration of how the indicator reads, not a backtest.
  • Price, daily candles (hollow up, filled down)
  • OBV, in millions (solid line)
  • Signal line, SMA(20) of OBV (solid line, second color)
OBV, signal SMA(20) on S&P 500 ETF, dividend-adjusted prices, daily, October 30, 2025 to October 28, 2026. Illustration of how the indicator reads, not a backtest.

It is not a rare case. Over the 250 days of the chart, from October 30, 2025 to October 28, 2026, the direction of the A/D line and the direction of the close disagreed on 58 days. On daily Bitcoin over its own last 250 days, from February 21, 2026, they disagreed on 34 days, and over the whole window the two volume lines told different stories: Bitcoin rose 19.59% from the February 20 close of 68,020.01 to 81,343.50, the A/D line ended higher, and on-balance volume ended lower.

Does it work?

We have no long-run measurement of the A/D line: our bench tests chart patterns detected by rule against random entries, not indicators (see our methodology). The examples above show how the line is built and where it disagrees with other volume measures, not whether its divergences predict anything. The ETF prices on the chart are adjusted for dividends; the adjustment scales the high, the low and the close together and leaves the multiplier unchanged.

Chaikin also built an oscillator from this line, the Chaikin oscillator, the gap between a 3-day and a 10-day exponential average of the A/D line. For other volume tools, see the Klinger oscillator, the price volume trend, or the full list of volume indicators.

Every pattern's results on one sheet

The only pattern cheat sheet with tested stats: 152 patterns, what the textbook says and what really happened on 6 markets. Free PDF, sent to your inbox.

The PDF by email, plus our newsletter: new tests and results that change. Unsubscribe anytime. Privacy.

Frequently asked questions

What is the accumulation distribution indicator?

A running total of volume, weighted each bar by where the close sits in the high-low range, developed by Marc Chaikin. It rises when closes are near the highs on volume and falls when they are near the lows.

What is the difference between the A/D line and on-balance volume?

On-balance volume adds the whole volume on an up close and subtracts it on a down close, compared with the previous close. The A/D line ignores the previous close and looks at where the close sits inside the bar. After a gap, the two can move in opposite directions.

What does a rising accumulation distribution line mean?

That recent closes have been mostly in the upper half of their bars, with volume behind them. It is read as buying pressure, but it does not say anything about gaps between bars.

Is the accumulation distribution line the same as the accumulation distribution index?

The names are used for the same indicator. StockCharts calls it the Accumulation Distribution Line and notes that Chaikin first called it the Cumulative Money Flow Line.
