RSI Divergence: The Rule, the Four Types, and What Every Signal Did Next

Price makes a new high or low and the RSI does not. How we mark RSI divergences by a fixed rule, the regular and hidden types, and what each divergence on Bitcoin and the S&P 500 ETF was followed by.

· Founder of PatternsWizard
Checked 12 min read
RSI(14) with divergences, swing points with 5 bars on each side, at most 60 bars apart on Bitcoin, daily, August 30, 2026 to October 28, 2026. Illustration of how the indicator reads, not a backtest.
On this page
  1. What an RSI divergence is
  2. How we mark a divergence: the rule
  3. Regular and hidden divergences
  4. Every regular divergence on Bitcoin, and what followed
  5. A strong trend: the S&P 500 ETF
  6. RSI 9, 14 or 21?
  7. Does it work?
  8. Frequently asked questions

An RSI divergence is a disagreement between price and the Relative Strength Index: price makes a higher high while the RSI makes a lower high (bearish), or price makes a lower low while the RSI makes a higher low (bullish). J. Welles Wilder, who published the RSI in 1978, read it as a sign that momentum no longer confirms the move. Below: the exact rule we use to mark divergences on the chart, the four types, and what every divergence on Bitcoin and the S&P 500 ETF did next, including the ones that failed.

RSI(14) divergences on Bitcoin, marked by rule

RSI(14) with divergences, swing points with 5 bars on each side, at most 60 bars apart on Bitcoin, daily, February 21, 2026 to October 28, 2026. Illustration of how the indicator reads, not a backtest.
  • Price, daily candles (hollow up, filled down)
  • RSI(14) (solid line)
  • Regular bullish: lower low in price, higher low in the oscillator
  • Hidden bearish: lower high in price, higher high in the oscillator (dashed)
  • Hidden bullish: higher low in price, lower low in the oscillator (dashed)
RSI(14) with divergences, swing points with 5 bars on each side, at most 60 bars apart on Bitcoin, daily, February 21, 2026 to October 28, 2026. Illustration of how the indicator reads, not a backtest.Solid lines: regular divergences; dashed: hidden ones. Each line joins two swing points of the same kind, in price and in the RSI. A divergence whose first swing falls before the window is not drawn.

What an RSI divergence is

StockCharts, following Wilder, gives the two classic definitions. “A bullish divergence occurs when the underlying security makes a lower low, and RSI forms a higher low.” “A bearish divergence forms when the security records a higher high and RSI forms a lower high.” According to Wilder, divergences signal a potential reversal point “because directional momentum does not confirm price.”

Two warnings come from the same page. Divergences “tend to be more robust when they form after an overbought or oversold reading,” that is above 70 or below 30. And they “are misleading in a strong trend”: a strong uptrend can show numerous bearish divergences before a top. Both claims can be checked on real data, which is what the rest of this page does. To judge how strong a trend is, Wilder also built the average directional index, published in the same 1978 book as the RSI.

How we mark a divergence: the rule

A divergence line drawn by hand, after the fact, is easy to fit to what happened. Ours are drawn by a fixed rule, the same on every bar:

  1. A swing high is a bar whose high is strictly above the highs of the 5 bars before and the 5 bars after it. A swing low is the same with lows.
  2. Each swing high is compared with the swing high just before it, if the two are at most 60 bars apart. Same for swing lows.
  3. The RSI(14) is read on the two swing bars, and the four comparisons below decide the type.

The rule has a cost that hand-drawn charts hide: a swing high is only known 5 bars after it happens, since the next 5 highs must be lower. A divergence can therefore be acted on 5 bars after its second swing at the earliest. All the returns below are measured from the close of that confirmation bar, not from the swing itself.

The June 2026 bullish divergences on daily Bitcoin, up close

RSI(14) with divergences, swing points with 5 bars on each side, at most 60 bars apart on Bitcoin, daily, May 27, 2026 to July 25, 2026. Illustration of how the indicator reads, not a backtest.
  • Price, daily candles (hollow up, filled down)
  • RSI(14) (solid line)
  • Regular bullish: lower low in price, higher low in the oscillator
  • Hidden bearish: lower high in price, higher high in the oscillator (dashed)
RSI(14) with divergences, swing points with 5 bars on each side, at most 60 bars apart on Bitcoin, daily, May 27, 2026 to July 25, 2026. Illustration of how the indicator reads, not a backtest.The lows of June 5 and June 25, then June 25 and July 1: each pair is joined in price and in the RSI(14). The rule could only mark them 5 bars after the second low. The dashed red line is a hidden bearish divergence, June 15 to July 6.

Regular and hidden divergences

Besides Wilder’s two regular divergences, the chart marks two hidden ones (dashed). StockCharts credits them to Andrew Cardwell under another name: a “positive reversal forms when RSI forges a lower low, and the security forms a higher low”, and a negative reversal is the opposite. Cardwell read divergences differently from Wilder: he “considered bearish divergences to be bull market phenomena,” more likely to form in uptrends.

The four RSI divergences

The four RSI divergences: four panels, each with price on top and the RSI below, and the two swing points compared joined by a segment, solid for regular and dashed for hidden divergences. Regular bearish: price makes a higher high, the RSI a lower high. Regular bullish: price makes a lower low, the RSI a higher low. Hidden bearish: price makes a lower high, the RSI a higher high. Hidden bullish: price makes a higher low, the RSI a lower low.
Schematic, not market data. The RSI is read on the swing bars of price, not on its own peaks and troughs.
TypePriceRSIUsual reading
Regular bearishHigher highLower highUptrend losing momentum (Wilder)
Regular bullishLower lowHigher lowDowntrend losing momentum (Wilder)
Hidden bearishLower highHigher highNegative reversal (Cardwell): downtrend continuing
Hidden bullishHigher lowLower lowPositive reversal (Cardwell): uptrend continuing

Every regular divergence on Bitcoin, and what followed

We ran the rule on all our daily Bitcoin bars. The rule waits 43 days for the RSI(14) to settle, so the first usable bar is April 20, 2025, and the last is October 28, 2026. The rule found 7 regular divergences and 8 hidden ones (one more hidden one is discarded: its first swing falls before April 20). Here are all 7 regular ones, with the price change from the confirmation close. For a bearish divergence, a fall is the expected direction; a short sold at the confirmation close would have returned the same percentage with the sign reversed.

TypeFirst swingSecond swingConfirmed, closeAfter 5 daysAfter 10 daysAfter 20 days
BearishMay 2, 2025: high 97,895.68, RSI 70.10May 12, 2025: high 105,819.45, RSI 69.40May 17, 2025: 103,126.65+8.31%+5.64%+1.13%
BearishJuly 14, 2025: high 123,218.00, RSI 75.95August 14, 2025: high 124,474.00, RSI 53.25August 19, 2025: 112,872.94+0.55%−3.98%−0.72%
BullishSeptember 26, 2025: low 108,620.07, RSI 38.39October 10, 2025: low 102,000.00, RSI 41.78October 15, 2025: 110,763.28−0.21%+0.80%−8.37%
BullishFebruary 12, 2026: low 65,118.00, RSI 29.33February 24, 2026: low 62,510.28, RSI 30.70March 1, 2026: 65,776.47+3.55%+6.71%+4.78%
BullishJune 5, 2026: low 59,130.91, RSI 15.62June 25, 2026: low 58,115.01, RSI 30.54June 30, 2026: 58,624.71+8.57%+9.44%+11.31%
BullishJune 25, 2026: low 58,115.01, RSI 30.54July 1, 2026: low 57,800.19, RSI 37.21July 6, 2026: 64,042.02−0.35%−0.33%+2.12%
BullishOctober 8, 2026: low 80,393.56, RSI 47.05October 15, 2026: low 79,800.00, RSI 48.88October 20, 2026: 83,028.15−3.46%not yet knownnot yet known

Ten days after each regular divergence on Bitcoin, in the expected direction

Ten days after each regular divergence on Bitcoin, in the expected direction. Bearish, confirmed May 17, 2025: −5.64%; Bearish, confirmed August 19, 2025: +3.98%; Bullish, confirmed October 15, 2025: +0.80%; Bullish, confirmed March 1, 2026: +6.71%; Bullish, confirmed June 30, 2026: +9.44%; Bullish, confirmed July 6, 2026: −0.33%. Our computation; the inputs and the method are in the text.
Our computation; the inputs and the method are in the text.Price change from the confirmation close to ten days later, sign reversed for the bearish cases so that a positive bar means the divergence was right. The October 20, 2026 case has no ten days of history yet.

Of the 6 regular divergences with ten days of history after them, price moved in the expected direction 4 times after ten days and 4 times after twenty. The first bearish one was wrong at every horizon: Bitcoin was 8.31% higher five days after it. The October 2025 bullish one was right after ten days by 0.80%, then wrong by 8.37% after twenty. For comparison, on any day of the same period Bitcoin closed higher ten days later 275 times out of 547, about half the time.

Divergences against the base rate of the same period

Divergences against the base rate of the same period. Bitcoin: divergence right after 10 days: 4 of 6; Bitcoin: any day, higher 10 days later: 275 of 547; ETF: bearish, lower 20 sessions later: 2 of 10; ETF: any session, lower 20 sessions later: 157 of 537. Our computation; the inputs and the method are in the text.
Our computation; the inputs and the method are in the text.Bitcoin from April 20, 2025 and the S&P 500 ETF from August 9, 2024, to October 28, 2026; returns from the close of the confirmation bar. Six and ten cases cannot be told apart from the base rate.

The overbought and oversold filter is one of the few things the sample can test, barely. Four of the regular divergences had their first swing at 70 or above (bearish) or at 30 or below (bullish): May 2025, July 2025, February 2026 and June 2026. Three of the four went the expected way after ten and twenty days. The two others with ten days of history, in October 2025 and July 2026, were each right at one horizon and wrong at the other. Four cases cannot separate a filter from luck.

A strong trend: the S&P 500 ETF

RSI(14) divergences on the daily S&P 500 ETF, marked by rule

RSI(14) with divergences, swing points with 5 bars on each side, at most 60 bars apart on S&P 500 ETF, dividend-adjusted prices, daily, October 30, 2025 to October 28, 2026. Illustration of how the indicator reads, not a backtest.
  • Price, daily candles (hollow up, filled down)
  • RSI(14) (solid line)
  • Regular bearish: higher high in price, lower high in the oscillator
  • Regular bullish: lower low in price, higher low in the oscillator
  • Hidden bearish: lower high in price, higher high in the oscillator (dashed)
RSI(14) with divergences, swing points with 5 bars on each side, at most 60 bars apart on S&P 500 ETF, dividend-adjusted prices, daily, October 30, 2025 to October 28, 2026. Illustration of how the indicator reads, not a backtest.Same rule as on Bitcoin: solid lines are regular divergences, dashed ones hidden. Most of the regular ones are bearish, in a market that kept rising. A divergence whose first swing falls before the window is not drawn.

The S&P 500 ETF shows the second warning. From August 9, 2024, the first usable bar, to October 28, 2026, it rose from 519.37 to 772.31 in our dividend-adjusted data. Prices are rounded to four decimals; at that precision the highs of January 12 and 13, 2026 are equal (690.70), so neither is a swing high. Over that period the rule found 10 regular bearish divergences against 1 bullish one. Twenty sessions after confirmation, the ETF was lower after only 2 of the 10 bearish ones: February 2025 (−4.08%) and February 2026 (−0.71%). On any session of the same period it was lower twenty sessions later 157 times out of 537, about 29%. On 10 cases, 2 lower closes against a base rate of about 29% is no evidence either way; what the table does show is the warning StockCharts gives: in a strong uptrend, bearish divergences keep appearing while the price keeps rising. All 11, with the price change from the confirmation close:

TypeSecond swingConfirmed, closeAfter 5 sessionsAfter 10After 20
BearishOctober 17, 2024October 24, 2024: 566.17−1.83%+2.83%+2.49%
BearishFebruary 19, 2025February 26, 2025: 583.08−1.93%−6.00%−4.08%
BearishJune 11, 2025June 18, 2025: 587.69+2.72%+4.98%+5.36%
BearishJuly 31, 2025August 7, 2025: 623.77+2.01%+0.52%+2.37%
BearishSeptember 23, 2025September 30, 2025: 659.07+0.44%−0.59%+3.13%
BearishOctober 10, 2025October 17, 2025: 657.30+1.94%+2.66%+1.13%
BearishDecember 26, 2025January 5, 2026: 682.39+1.08%−1.47%+0.26%
BearishJanuary 28, 2026February 4, 2026: 680.87+0.84%−0.25%−0.71%
BullishFebruary 17, 2026February 24, 2026: 682.02−1.02%−1.48%−4.71%
BearishJune 2, 2026June 9, 2026: 733.34+1.80%−0.26%+2.25%
BearishJuly 15, 2026July 22, 2026: 745.56−2.40%+2.99%+2.90%

The only bullish divergence failed as well: the ETF was 4.71% lower twenty sessions after it.

RSI 9, 14 or 21?

The same rule with three RSI lengths, regular divergences only. A longer RSI needs a longer warm-up, so its first usable bar comes a few days later: April 5, April 20 and May 11, 2025 on Bitcoin; July 19, August 9 and September 10, 2024 on the ETF. The rule found 8, 7 and 7 regular divergences on Bitcoin, and 11, 11 and 8 on the ETF; the chart counts those with ten or twenty bars of history after confirmation.

Share of regular divergences that went the expected way

Share of regular divergences that went the expected way. Bitcoin, RSI(9): After 10 bars 4 of 7, After 20 bars 3 of 7; Bitcoin, RSI(14): After 10 bars 4 of 6, After 20 bars 4 of 6; Bitcoin, RSI(21): After 10 bars 5 of 7, After 20 bars 6 of 7; S&P 500 ETF, RSI(9): After 10 bars 5 of 11, After 20 bars 2 of 11; S&P 500 ETF, RSI(14): After 10 bars 5 of 11, After 20 bars 2 of 11; S&P 500 ETF, RSI(21): After 10 bars 4 of 8, After 20 bars 2 of 8. Our computation; the inputs and the method are in the text.
  • After 10 bars
  • After 20 bars
Our computation; the inputs and the method are in the text.Swing points with 5 bars on each side, at most 60 bars apart, returns from the close of the confirmation bar, daily bars to October 28, 2026. Samples of 6 to 11 cases: too few to rank the lengths.

On Bitcoin the RSI(21) looks best, on 7 cases; on the ETF no length escapes the trend. Picking the length that worked best on such samples is how a backtest overfits.

Does it work?

We have no long-run measurement of RSI divergences: our bench tests chart patterns detected by rule against random entries, not indicators (see our methodology). What the counts above show is narrow: on Bitcoin, regular divergences went the expected way 4 times out of 6, too few to tell from chance; on a rising ETF, bearish divergences mostly failed. Treat a divergence as a reason to look at the chart, then wait for price to confirm, for example a break of a trendline or of the neckline of a double top.

Related pages: the Relative Strength Index itself, divergences on other oscillators, such as the MACD and the stochastic, the stochastic RSI, and the list of technical indicators.

Every pattern's results on one sheet

The only pattern cheat sheet with tested stats: 152 patterns, what the textbook says and what really happened on 6 markets. Free PDF, sent to your inbox.

The PDF by email, plus our newsletter: new tests and results that change. Unsubscribe anytime. Privacy.

Frequently asked questions

What is RSI divergence?

A disagreement between price and the RSI: price makes a higher high while the RSI makes a lower high (bearish), or price makes a lower low while the RSI makes a higher low (bullish). Wilder read it as momentum no longer confirming the move.

Is RSI divergence profitable?

Not shown. On Bitcoin from April 2025 to October 2026, 4 of 6 regular divergences went the expected way after ten days, a sample too small to separate from chance; on the rising S&P 500 ETF, only 2 of 10 bearish divergences were followed by a lower close twenty sessions later.

What is the difference between regular and hidden divergence?

A regular divergence points to a reversal: price extends the trend, the RSI does not. A hidden divergence points to a continuation: price holds a higher low (or a lower high) while the RSI makes a lower low (or a higher high). StockCharts calls these Cardwell’s positive and negative reversals.

How do you confirm an RSI divergence?

First the swing itself must be confirmed: with our rule, 5 bars must pass after the second swing. Then wait for price to confirm, for example a break of a trendline. Our counts are measured from the first of these two steps only.

Which RSI setting is best for divergence?

None has been shown to be. On our data the RSI(21) did best on Bitcoin, on 7 cases, and no length did well on the S&P 500 ETF; choosing the best length on such small samples is overfitting.
